Professional Lab Clean Room Sotion
Production Introduction
Structural materials:
Clean room walls and ceiling materials are generally made of 50mm thick sandwich color steel plates and alumina profiles for purification. The door adopts a clean airtight door, and the window adopts aluminum alloy glass fixed window.
The floor adopts epoxy self-leveling or high-grade wear-resistant plastic clean floor.
| Engineering technical parameters of dust-free workshop | 1.Ten thousand class 15-25 times/hour; 2.Thousands of 50-52 times/hour; 3.The cross-sectional wind speed of the hundred-level console is 0.25-0.35m/s; |
| Pressure difference | the main workshop to the adjacent clean room ≥5Pa; the clean room to the non-clean area ≥10Pa; |
| Temperature | Winter ＞16℃±2℃; Summer ＜26℃±2℃; |
| Relative humidity | 45-65% (RH); |
| Noise | ≤65dB (A) |
| Fresh air supplement | 20%-30% of the total air supply; |
| Illumination | ≥300Lux. The purification ventilation duct is made of galvanized sheet steel, and the "PEF" flame-retardant insulation board is used for insulation. |
If you're looking for the professional lab clean room sotion, BOKA must be your best choice. As one of the leading manufacturers and suppliers in China, our factory has great competence in this field. Welcome to buy our low price products and check the price list with us.
